Hybrid surface treatment technologies based on the electrospark alloying method
DOI:
https://doi.org/10.15407/mom2026.03.014Keywords:
functional coatings, surface plastic deformation, laser treatment, magnetron sputtering, metal-polymer materialAbstract
The formation of functional coatings is one of the promising approaches to improving the durability, hardness and wear resistance of machine parts and tools. Electrospark alloying (ESA) has proven to be an effective technology for local surface modification, offering minimal thermal impact, high adhesion and the ability to use a wide range of conductive materials to produce coatings with tailored properties. At the same time, further improvement of ESA is closely linked to the development of hybrid technologies that expand coating functionality and eliminate the shortcomings of individual methods.
The paper reviews the current state of ESA technology and analyzes the main schemes for its combination with other processing methods. Special attention is given to integration with surface plastic deformation, laser treatment, metal-polymer materials, and magnetron sputtering. It is shown that these combinations allow the formation of coatings with higher microhardness, wear resistance, corrosion resistance, controlled roughness, and improved tribological characteristics. Industrial aspects of implementing hybrid technologies are also considered.
Key challenges are identified, including the multiparametric nature of hybrid treatments, the complexity of controlling the stress-strain state, the need for mode optimization, and the lack of real‑time automated control systems. The use of machine learning for predicting coating properties, intelligent parameter selection, and adaptive process control is proposed. The main directions for further research are outlined: quantitative optimization of hybrid processing parameters, development of physical and mathematical models of coating formation, analysis of residual stresses and long-term operability in real conditions, and creation of digital decision support systems. The implementation of these tasks will facilitate the transformation of ESA‑based hybrid technologies into highly effective surface engineering tools for a wide range of industrial applications.
References
Hahn, D. W., & Omenetto, N. (2012). Laser-induced breakdown spectroscopy (LIBS), Part II: Review of instrumental and methodological approaches to material analysis and applications to different fields. Applied Spectroscopy, 66(4), 347–419. https://doi.org/10.1366/11-06574
Tracton, A. A. (2006). Coatings technology handbook. Taylor & Francis. https://doi.org/10.1201/9781420044089
Martsinkovsky, V., Yurko, V., Tarelnik, V., & Filonenko, Y. (2012). Designing thrust sliding bearings of high bearing capacity. Procedia Engineering, 39, 148–156. https://doi.org/10.1016/j.proeng.2012.07.019
Pogrebnjak, A. D., Bagdasaryan, A. A., Horodek, P., Tarelnyk, V., Buranich, V. V., Amekura, H., Okubo, N., Ishikawa, N., & Beresnev, V. M. (2021). Positron annihilation studies of defect structure of (TiZrHfNbV)N nitride coatings under Xe14+ 200 MeV ion irradiation. Materials Letters, 303, 130548. https://doi.org/10.1016/j.matlet.2021.130548
Liu, Y., Zhang, S., Shao, W., Wang, Z., Qu, J., Zhou, W., & Zhang, S. (2025). Research on the influence of magnetic field assistance on the quality of an electro-spark deposition layer. Coatings, 15, 88. https://doi.org/10.3390/coatings15010088
Tarelnyk, V. B., Gaponova, O. P., Loboda, V. B., Konoplyanchenko, E. V., Martsinkovskii, V. S., Semirnenko, Y. I., Tarelnyk, N. V., Mikulina, M. A., & Sarzhanov, B. A. (2021). Improving ecological safety when forming wear-resistant coatings on the surfaces of rotation body parts of 12Kh18N10T steel using a combined technology based on electrospark alloying. Surface Engineering and Applied Electrochemistry, 57, 173–184. https://doi.org/10.3103/S1068375521020113
Barile, C., Casavola, C., Pappalettera, G., & Renna, G. (2022). Advancements in electrospark deposition (ESD) technique: A short review. Coatings, 12, 1536. https://doi.org/10.3390/coatings12101536
Wang, J., Zhang, M., Dai, S., & Zhu, L. (2023). Research progress in electrospark deposition coatings on titanium alloy surfaces: A short review. Coatings, 13, 1473. https://doi.org/10.3390/coatings13081473
Tarelnyk, V. B., Gaponova, O. P., Konoplianchenko, Ye. V., Martsynkovskyy, V. S., Tarelnyk, N. V., & Vasylenko, O. O. (2019). Improvement of quality of the surface electroerosive alloyed layers by the combined coatings and the surface plastic deformation. I. Features of formation of the combined electroerosive coatings on special steels and alloys. Metallofizika i Noveishie Tekhnologii, 41(1), 47–69. https://doi.org/10.15407/mfint.41.01.0047
Oppong, B. G., Geambazu, L. E., Ormsdottir, A. M., Gunnarsson, B. G., Csaki, I., Fanicchia, F., Kovalov, D., & Karlsdottir, S. N. (2022). Microstructural properties and wear resistance of Fe-Cr-Co-Ni-Mo-based high-entropy alloy coatings deposited with different coating techniques. Applied Sciences, 12, 3156. https://doi.org/10.3390/app12063156
Haponova, O., Tarelnyk, V., Mościcki, T., Tarelnyk, N., Półrolniczak, J., Myslyvchenko, O., Adamczyk-Cieślak, B., & Sulej-Chojnacka, J. (2024). Investigation of the structure and properties of MoS2 coatings obtained by electrospark alloying. Coatings, 14, 563. https://doi.org/10.3390/coatings14050563
Tarelnyk, V., Gaponova, O., Martsynkovskyy, V., Kutakh, A., & Golovchenko, G. (2021). New process for nitriding steel parts. In Proceedings of the 2021 IEEE 11th International Conference “Nanomaterials: Applications and Properties” (CFP21F65-ART, 176891). IEEE, Odessa, Ukraine. https://doi.org/10.1109/NAP51885.2021.9568563
Zhang, Z., Konoplianchenko, I., Tarelnyk, V., Liu, G., Du, X., & Yu, H. (2022). The characterization of running-in coatings on the surface of tin bronze by electro-spark deposition. Coatings, 12, 930. https://doi.org/10.3390/coatings12070930
Penyashki, T., Kostadinov, G., Kandeva, M., Nikolov, A., Dimitrova, R., Kamburov, V., Danailov, P., & Bozhkov, S. (2023). Study of the influence of coating roughness on the properties and wear resistance of electrospark deposited Ti6Al4V titanium alloy. Tribology in Industry, 46, 13–28. https://doi.org/10.24874/ti.1508.06.23.08
Radek, N., Pietraszek, J., Gądek-Moszczak, A., Orman, Ł. J., & Szczotok, A. (2020). The morphology and mechanical properties of ESD coatings before and after laser beam machining. Materials, 13, 2331. https://doi.org/10.3390/ma13102331
Tarelnyk, V. B. (1997). Kombinirowannyje technologii elektroerozionnogo liegirowania. Kyiv: Tekhnika. 128 p. [in Russian].
Gaponova, O. P., Tarelnyk, V. B., Martsynkovskyy, V. S., Konoplianchenko, Ie. V., Melnyk, V. I., Vlasovets, V. M., Sarzhanov, O. A., Tarelnyk, N. V., Mikulina, M. O., Polyvanyi, A. D., Kirik, G. V., & Batalova, A. B. (2021). Combined electrospark running-in coatings of bronze parts. Part 1. Structure and mechanical properties. Metallofizika i Noveishie Tekhnologii, 43(8), 1121–1138. [in Ukrainian]. https://doi.org/10.15407/mfint.43.08.1121
Tarel’nik, V. B., Martsinkovskii, V. S., & Zhukov, A. N. (2017). Increase in the reliability and durability of metal impulse end seals. Part 2. Chemical and Petroleum Engineering, 53, 266–272. https://doi.org/10.1007/s10556-017-0333-7
Tarelnyk, V. B., Gaponova, O. P., Konoplianchenko, Ye. V., Martsynkovskyy, V. S., Tarelnyk, N. V., & Vasylenko, O. O. (2019). Improvement of quality of the surface electroerosive alloyed layers by the combined coatings and the surface plastic deformation. III. The influence of the main technological parameters on microgeometry, structure and properties of electrolytic erosion coatings. Metallofizika i Noveishie Tekhnologii, 41(3), 313–335. [in Russian]. https://doi.org/10.15407/mfint.41.03.0313
Tarelnik, V. B., Antoshevsky, B., Martsinkovsky, V. S., Konoplyanchenko, E. V., & Belous, A. V. (2015). Tsementatsiya ehlektroehrozionnym legirovaniem: Monografiya [Cementation by electroerosive alloying: A monograph]. In V. B. Tarelnik (Ed.). Sumy: University Book. 233 pp. [in Russian].
Radek, N., Konstanty, J., Pietraszek, J., Orman, Ł. J., Szczepaniak, M., & Przestacki, D. (2021). The effect of laser beam processing on the properties of WC-Co coatings deposited on steel. Materials, 14, 538. https://doi.org/10.3390/ma14030538
Radek, N., Bronček, J., Fabian, P., Pietraszek, J., & Antoszewski, K. (2015). Properties of the electro-spark deposited coatings: Technology and applications. Materials Science Forum, 818, 61–64. https://doi.org/10.4028/www.scientific.net/MSF.818.61
Myslyvchenko, O., Lytvyn, R., Grinkevich, K., Zgalat-Lozynskyy, O., Bondar, A., Shyrokov, O., Ivanchenko, S., Bloschanevich, O., & Stegniy, A. (2024). Laser treatment of electrospark-deposited Ti0.8W0.25Cr0.5FeCo1.75Ni3AlB0.6 high-entropy coatings. JOM, 76, 3960–3968. https://doi.org/10.1007/s11837-024-06552-z
Paustovskii, A. V., & Botvinko, V. P. (2000). Phase composition of the surface layers of high-speed cutting steel after electrospark alloying and laser treatment. Materials Science, 36, 100–103. https://doi.org/10.1007/BF02805123
Lytvyn, R. V., Grinkevich, K. E., Myslyvchenko, O. M., Trachenko, I. V., Bloschanevych, O. M., Ivanchenko, S. E., Derev’yanko, O. V., Stegniy, A. I., Belik, V. D., & Zgalat-Lozynskyy, O. B. (2024). Wear-resistant coatings produced from TiN–TiB2 and TiN–Si3N4 composites by electrospark deposition and laser processing. Powder Metallurgy and Metal Ceramics, 62, 611–620. https://doi.org/10.1007/s11106-024-00421-9
Feldshtein, E. E., Kardapolova, M. A., Gaida, R., Khorodyski, B., & Kaval’chuk, O. V. (2013). Tribological properties of electro-spark-deposited and further laser-hardened coatings. Journal of Friction and Wear, 34, 137–141. https://doi.org/10.3103/S1068366613020049
Rukanskis, M. (2019). Control of metal surface mechanical and tribological characteristics using cost-effective electro-spark deposition. Surface Engineering and Applied Electrochemistry, 55, 607–619. https://doi.org/10.3103/S1068375519050107
Verbitchi, V., Ciuca, C., & Cojocaru, R. (2011). Electro-spark coating with special materials. Nonconventional Technologies Review, 1, 57–62.
Martsinkovskyy, V. S., Tarelnyk, V. B., Pavlov, O. G., & Ischenko, A. O. (Patent holders). (n.d.). The method for restoration of worn surfaces of metal parts (variants) (Patent UA 104664). Bulletin 4, p. 3. Available online: https://iprop-ua.com/inv/pdf/ep4z7c9e-pub-description.pdf (accessed 12 May 2026). [in Ukrainian].
Lešnjak, A., & Tušek, J. (2002). Processes and properties of deposits in electrospark deposition. Science and Technology of Welding and Joining, 7, 391–396. https://doi.org/10.1179/136217102225006886
Ishchenko, A. O. (2008). Tekhnolohichni zasady vidnovlennia promyslovoho obladnannia suchasnymy polimernymy materialamy. PDTU, Mariupol, Ukraina. 247 p. [in Ukrainian].
Tarelnik, V. B., Martsinkovsky, V. S., Pavlov, O. G., & Sarzhanov, B. O. (Patent holders). (2018). The method of restoring worn surfaces of metal parts (Patent of Ukraine No. 117980 UA; MPK B23H 1/00, B23H 5/02 (2006.01), B23H 5/04 (2006.01), B23P 6/00, C23C 28/00). Application 10.04.2017; Publication 25.10.2018, Bulletin No. 20. Available online: https://iprop-ua.com/inv/pdf/2squcp00-pub-description.pdf (accessed 12 May 2026). [in Ukrainian].
Tarelnyk, V., Martsynkovskyy, V., Sarzhanov, A., Pavlov, A., Gerasimenko, V., & Sarzhanov, B. (2017). Improvement of integrated technology for restoring surfaces of steel and iron parts. IOP Conference Series: Materials Science and Engineering, 233, 012050. https://doi.org/10.1088/1757-899X/233/1/012050
Tarelnyk, V., Konoplianchenko, I., Gaponova, O., Tarelnyk, N. V., Martsynkovskyy, V. S., Sarzhanov, B. O., Sarzhanov, O. A., & Antoszewski, B. (2020). Effect of laser processing on the qualitative parameters of protective abrasion-resistant coatings. Powder Metallurgy and Metal Ceramics, 58, 703–713. https://doi.org/10.1007/s11106-020-00127-8
Berladir, K., Hovorun, T., Botko, F., Radchenko, S., & Oleshko, O. (2025). Thin modified nitrided layers of high-speed steels. Materials, 18, 2434. https://doi.org/10.3390/ma18112434
Tekin, T., Ischia, G., Naclerio, F., Ipek, R., Bandini, M., Molinari, A., & Benedetti, M. (2025). Unveiling the impact of nitriding and PVD coating on the fatigue properties of L-PBF maraging steel. Materials Science and Engineering A, 935, 148365. https://doi.org/10.1016/j.msea.2025.148365
Wang, X., Wang, Y., Ling, Z., et al. (2025). Strategies for superhard tool coating materials: Focus on preparation methods and properties. Journal of Iron and Steel Research International, 32, 2232–2266. https://doi.org/10.1007/s42243-025-01448-x
Marcinkovsky, V. S., & Tarelnik, V. B. (Patent holders). (2013). The method of strengthening the surface of steel parts subjected to heat treatment (Patent of Ukraine No. 103701; MPK 23N 5/00). Publication 11.11.2013, Bulletin No. 21. Available online: https://iprop-ua.com/inv/pdf/2y6qkr4h-pub-description.pdf (accessed 15 April 2025). [in Ukrainian]
Tarelnyk, V. B., Konoplianchenko, I., Gaponova, O. P., Radionov, O., Antoszewski, B., Kundera, C., Tarelnyk, N. V., Voloshko, T., Bondarev, S. G., Gerasimenko, V. O., et al. (2022). Application of wear-resistant nanostructures formed by ion nitridizing & electrospark alloying for protection of rolling bearing seat surfaces. In Proceedings of the IEEE 12th International Conference Nanomaterials: Applications & Properties (NAP) 2022, Krakow, Poland, 11–16 September 2022 (pp. 01–08). https://doi.org/10.1109/NAP55339.2022.9934739
Béjar, M. A., Schnake, W., Saavedra, W., & Vildósola, J. P. (2006). Surface hardening of metallic alloys by electrospark deposition followed by plasma nitriding. Journal of Materials Processing Technology, 176, 210–213. https://doi.org/10.1016/j.jmatprotec.2006.03.162
Abdi, F., Aghajani, H., & Asl, S. K. (2023). Evaluation of the corrosion resistance of AlCoCrFeMnNi high-entropy alloy hard coating applied by electro-spark deposition. Surface and Coatings Technology, 454, 129156. https://doi.org/10.1016/j.surfcoat.2022.129156
Abdi, F., Aghajani, H., Tabrizi, A. T., Nasimi, L., & Shokouhi, F. F. (2023). Study on the effect of the crack closing of AlCoCrFeMnNi high-entropy alloy electro-spark deposited coating by plasma nitriding on the corrosion resistance. Journal of Alloys and Compounds, 966, 171629. https://doi.org/10.1016/j.jallcom.2023.171629
Smirnov, I. V., Glukhovskyy, V. Y., & Kopylov, V. I. (2007). Multicomponent coatings created by combination of magnetron deposition and electrospark alloying. Naukovi Visti NTUU-KPI, 6, 86–91. [in Ukrainian]
Lu, K., Zhu, J., Ge, W., & Hui, X. (2022). Progress on new preparation methods, microstructures, and protective properties of high-entropy alloy coatings. Coatings, 12, 1472. https://doi.org/10.3390/coatings12101472
